摘 要
跟着社会文明的成长与进步，运输作为手段也不断发展，机械式连续输送机获得了广泛的使用。链条输送机以其能在高温和低温恶劣环境下工作，也能低速运行，此外在水平内循环与陡坡度的条件下搬运货物的优点，得到使用者的认可。而且其装卸不用停车，可以高速度进行运输，有很高的生产率，因为链条输送机供料均匀与运行速度稳定，工作过程中消耗的功率很小，寿命长。
链条输送机的设计主要包括确定底板宽度、确定裙板高度、载荷的计算及校核、选择输送链、链轮的设计、驱动链轮轴的设计、轴的疲劳强度校核、选配电动机、选择滚动轴承、选择联轴器等。
关键字：链条输送机；运输；速度；生产率
Abstract
Along with the social civilization development and the progress, transport as the method also unceasingly develops, in all transport vehicle, mechanical type continual conveyer to widespread use. The chain link conveyer by its can works under the high temperature and the low temperature environment, also can the low speed movement, as well as transports the cargo in the horizontal internal recycling and under the steep gradient condition the merit obtains user's favor. Moreover its loading and unloading does not need to stop, may the high velocity carry on the transportation, has the very high productivity, because chain link conveyer for material evenly with running rate stable, in the work process consumes power small, the life is long.
The design of chain conveyor including the width of the main floor, a high degree of calculation, the load calculation and verification, the choice of chain link, the design of sprocket,the design of chain drive shaft, check the shaft fatigue, Motor-matching, and the choice of rolling bearings, the choice of coupling.
Through the above listed in the calculation and verification ,achieving my purpose. So that the function of the chain conveyor reasonable, simple and practical, reliable, and so on.
Key words: chain link conveyer ;Transportation; Speed; Productivity
目录
摘 要
Abstract
目录
1 绪 论
1.1链条输送机的发展及行业现状
1.2 链条输送机的作用及特点
1.3 链条输送机的主要组成部分
2 方案的选定
2.1 链条输送机的种类
2.2 承托式链条输送机的特点
2.3布置形式
3 链条输送机的设计
3.1 原始数据
3.2 参数的选择与确定
3.3 各个参数的设计计算
3.4 输送链的选择及其尺寸
3.5 链轮的设计
3.5.1 链轮各直径的设计计算
3.5.2 链轮齿廓参数计算
3.5.3 链轮轴向齿廓形状参数计算
3.6 驱动链轮轴的设计
3.6.1 驱动链轮轴的初步设计
3.6.2轴的结构设计
3.6.3轴的强度较核
3.7带轮的传动设计
3.7.1带轮型号的选择
3.7.2大小带轮的尺寸确定
3.7.3 V带传动的中心距的确定及小带轮的包角验算
2.7.4 V带传动的皮带根数的确定
3.7.5小、大带轮的结构
3.8电动机的选配
3.9 滚动轴承的选择与计算
3.10联轴器的选择
3.11主要部件结构设计
4 板式输送机的安装与调整
4.1安装技术要求
4.2输送机的调整
5 总结
6 谢辞
7 参考文献
