摘 要

本文旨在设计与实现一款基于STM32的数模混合同传装置，该装置能够实现对模拟信号与数字信号的同步传输与处理。首先，本文简述了模拟信号与数字信号的基本概念及其特点，明确了数模混合传输的必要性和应用场景。随后，根据设计任务与要求，制定了总体方案设计，并详细论证了方案的可行性。装置设计过程中，采用了STM32微控制器作为核心控制单元，结合模拟信号调理电路和数字信号处理模块，实现了对信号的采集、转换、传输及处理。通过实物制作与测试，验证了装置的可靠性和稳定性，并对其进行了优化与调试。本文的研究成果不仅为数模混合信号的传输提供了有效的解决方案，也为相关领域的研究与应用提供了参考。

关键词：STM32；数模混合；同传装置；模拟信号；数字信号

Abstract

This paper aims to design and implement a digital-analog hybrid transmission device based on STM 32 to realize the synchronous transmission and processing of analog and digital signals. Firstly, this paper briefly describes the basic concepts and characteristics of analog and digital signals, and clarifies the necessity and application scenarios of digital-analog hybrid transmission. Subsequently, according to the design tasks and requirements, the overall scheme design was formulated, and the feasibility of the scheme was demonstrated in detail. In the design process of the device, the STM 32 microcontroller is adopted as the core control unit, combined with the analog signal conditioning circuit and the digital signal processing module, to realize the signal acquisition, conversion, transmission and processing. The reliability and stability of the device were verified through physical production and testing, and it was optimized and debugged. The research results of this paper not only provide an effective solution for the transmission of digital-analog hybrid signals, but also provide a reference for the research and application in related fields.

Key words: STM 32; digital-analog mixing; simultaneous transmission device; analog signal; digital signal
