摘  要
苹果原产于欧洲中部和东南部、中亚、西亚和中国新疆。苹果是常见的水果之一。苹果树是属于蔷薇科的落叶乔木，叶子呈椭圆形、锯齿状。果实球形，味甜，脆脆，营养丰富，是世界四大水果之冠。苹果通常是红色的，但也有黄色和绿色的。苹果是一种低热量食物，每100 克只产生60 大卡热量。苹果中的营养成分被称为“矿泉水”，因为它们溶解度高，容易被人体吸收，并且溶解硫成分，使皮肤光滑柔软。
中国是世界上最大的苹果生产国和消费国，占世界苹果种植面积和产量的40%以上，在世界苹果产业中占有重要地位。苹果消费市场以新鲜水果和加工产品为主，新鲜食品占比达到90%，加工产品占比10%左右。为保证苹果质量，及时收获是我国苹果产业的重中之重。繁重的采摘工作量和劳动力的缺乏使得及时采摘变得越来越困难。
根据季节的不同，采摘是劳动密集型的，而且价格昂贵。水果采摘是水果生产链中最耗时耗力的环节。因此，及时收获水果，降低收获作业成本是增加农业收入的重要途径。采摘作业非常复杂，目前国内的水果采摘作业基本都是人工完成，成本约占成本的50-70%，时间相对密集。采摘机作为一种重要的农业机械，可以降低劳动强度和生产成本，提高劳动生产率和产品质量，及时收获果实，具有很大的发展潜力。
关键词：农业机械；机械手；输送机构；苹果；采摘机
Abstract
Apple is native to central and southeastern Europe, Central Asia, West Asia, and Xinjiang, China.Apple is one of the common fruits.The apple tree is deciduous trees belonging to the Rosaceae with oval, serrated leaves.Fruit spherical, sweet taste, crisp, rich in nutrition, is the crown of the world's four major fruits.Apple are usually red, but are also yellow and green.Apples are a low-calorie food that produces only 60 calories per 100 grams.The nutrients in apples are called "mineral water" because they have high solubility, are easily absorbed by the body, and dissolve sulfur, making the skin smooth and soft.
China is the world's largest apple producer and consumer, accounting for more than 40% of the world's apple planting area and output, playing an important position in the world's apple industry.The Apple consumer market is mainly composed of fresh fruits and processed products, with fresh food accounting for 90% and processed products accounting for about 10%.In order to ensure the quality of apples, timely harvest is the top priority of China's apple industry.The heavy picking workload and lack of labor make it timely picking more and more difficult.
Depending on the season, the picking is labor-intensive and expensive.Fruit picking is the most time-consuming and power-consuming link in the fruit production chain.Therefore, timely harvest of fruit and reducing the cost of harvest operation is an important way to increase agricultural income.Picking work is very complex. At present, the fruit picking work in China is basically completed manually, with the cost accounting for about 50-70% of the cost, and the time is relatively intensive.As an important agricultural machinery, the picker can reduce labor intensity and production costs, improve labor productivity and product quality, and harvest fruits in time, which has great development potential.
Key words: agricultural machinery; manipulator; delivery mechanism; apple; picker
